Day 22.

The Model Shipways Fair American model ship kit has some tight curves at the bow, so the plans call for adding some filler blocks.

These filler blocks are shaped pieces of solid wood that fit between the bow and the first bulkhead. They are pretty simple, but require a lot of carving and sanding.

Slot And Filler Model

I started by cutting a block to the be about the right size. I clamped it into place, and tracked the shape of the first bulkhead onto the block. I cut that out using a small hand saw.

Next I used a Dremel with a sanding drum attached to rough in the overall shape. I left some extra material on there – I was just trying to get it roughly to the right size and shape.

The piece was then glued in.

The bow filler block is cut roughly to shape.

Filler

Once the glue was dry and the piece was secure, I sanded it by hand with some 80 grit sandpaper, followed by finer grits as the shape got closer. The goal is to create a smooth curve from the first bulkhead down to the rabbet line at the keel in the bow.

Once it is glued in, the filler block is sanded by hand to match the desired curves.

With the piece properly shaped and sanded smooth, I repeated the process for the other side.

And

The final step is to install the timberheads and knightheads. On the Fair American, these look just like the tops of the bulkheads – little posts that come up and will form the supports for the bulwarks later on.

Slot And Filler Models

When the hull is planked, the wooden strips for planking will need to bend to match the curve around the bow. Since this curve is pretty tight, these extra supports give us something to attach those planks to.

The timberheads and knightheads are shaped a little different, but the plans indicate that you can simply make them both identical if desired (since they will be covered by planking). I chose to take that route.

I started by shaping some 3/16″ thick wood strip to have the right curve for the timber heads. Then I held these up against the filler block and traced their outline onto the block. Using a couple different knife blades, I carved out a slot to hold the new piece.

The piece was then glued in, and everything was sanded down. This was repeated for a total of four pieces – two on each side.

Like the bulkheads, I roughed in the fairing, and will come back and do a final fairing on all these right before I start the hull planking.

Slot And Filler Model

The timberheads and knightheads are glued into place.
